Description
This Cast Steel Metal Seated Floating Ball Valve is a split trunnion mounted ball valve with a spring loaded valve seat with cavity overflow, and has double cut-off and discharge functions. It is made of high-quality metal materials, and its surface has been treated in various ways, which makes it have good wear resistance and corrosion resistance, and can ensure zero leakage during operation. At the same time, it is widely used to process various liquids, suspended solids and gases, and requires low maintenance, which can effectively reduce the use cost.
Features
Our Cast Steel Metal Seated Floating Ball Valve has a vinyl covered lever handle and locking device, which can realize flexible switch control. At the same time, it provides excellent corrosion resistance for most applications, can well avoid the impact of water, oil, natural gas and acid, and maintain good performance. In addition, it is equipped with a tight seal to ensure no leakage and maintain a lasting seal after years of frequent use.
Details
Material: WCB, WC6, WC9, CF8, CF8M, CF3, CF3M, LCC, LCB, LC1, LC2, LC3, etc.
Size Range: 1/2”-8”
Pressure Rating: ASME CL 150, 300, 600, 900, 1500, 2500
Temperature Range: -29°C~600°C
Standards
Design and Manufacture: API6D/ASME B16.34/BS5351
Face to Face Dimensions: API6D/ASME B16.10
Flange End Dimensions: ASME B16.5/ASME B16.47
Butt Welded Dimensions: ASME B16.25
Pressure Test: API 598/API6D
About us
Our technicians concentrate on research and innovation, and several new series ofCast Steel Metal Seated Floating Ball Valve are put on the market every year. We closely focus on the overall development strategy objectives of the company and deepen the implementation of the strategy of strengthening the enterprise with talents and the innovation-driven development strategy. Excellence is the pursuit of high-end customers for its value, but also the formation of our company brand differentiation, positioning the fundamental high-end image.
